Cage Nuts
Fast & easy to assemble by hand.
Need Assistance?
Contact our Engineering team now +44 (0)1435 866011
Product Information
¢ Fast & easy to assemble by hand.
¢ Self retaining.
¢ High strength.
¢ Blind fitting.
¢ Provide ˜float™ for misalignment of panels.
¢ Eliminates welding, clinching or staking.
Material:
Cage: CS70 Carbon Spring Steel or 302 S25 Stainless Steel (Suffix S)
Nut: Low Carbon Mild Steel or A2 Stainless Steel
Finish:
Blue Oil Dip & Spin, Electro Zinc & Yellow, Electro Zinc & Clear, Electro Zinc & Black, Mechanical Zinc & Yellow, Mechanical Zinc & Clear, Phosphate and Green, Xylan
Note: Plastic Coated Cage and Nylon 66 Nut available to order.
Colour for Cage: Red, Green, Blue, White, Black, Yellow and Grey.
Colour for Nylon 66 Nut: White or Black.
With ISO9001: 2015 approval incorporating Design Status, our qualified engineering staff are able to offer a completely free of charge engineering service and are available to assist with part selection, custom design, application requirements, material selection and more.
Applications are discussed in-depth, first-off design data and drawings are submitted for approval to ensure our customers are provided with the correct design, first time. However, on those rare occasions when modifications are necessary, our no-tooling process and flexible manufacturing procedures means the production of prototypes is easily and economically achieved without onerous tooling charges and long lead times.
At TFC we realise that Quality runs through the entire business, not just our products. We have continually invested in the right people to provide the superior market knowledge and customer service.
Our supply chain partners, from manufacturers to logistics and information technology are carefully chosen to ÿt our commitment to quality
Quality assured since 1981
ISO 9001:2015
Aerospace AS9100C & AS9120A
All products are batch traceable and can be supplied in accordance with REACH, RoHs and Weee.
Certificates of Conformity are available on request and Full material certification is also available on many items.
All dimensions in mm
| Product Code | Thread | Panel Range (F) | Width (b) | Length (l) | Height (h) | Hole Size (LxB) | Hole Radius | Design |
|---|---|---|---|---|---|---|---|---|
| C200 AR230285000 | M3 | 0.3 – 0.9 | 9.3 | 9.7 | 6.4 | 6.7 | ||
| C200 0201 | M3 | 0.7 – 1.6 | 10.0 | 10.0 | 4.8 | 6.8 | 0.5 | 2 |
| C200 AR230286000 | M3 | 1.0 – 1.6 | 9.3 | 9.7 | 7.5 | 6.7 | ||
| C200 AR230287000 | M4 | 0.5 – 1.6 | 10.0 | 10.3 | 5.0 | 6.7 | ||
| C200 0100 | M4 | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0200 | M4 | 0.7 – 1.6 | 10.0 | 10.0 | 4.8 | 6.8 | 0.5 | 2 |
| C200 0300 | M4 | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0302 | M4 | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0102 | M4 | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0304 | M5 | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0204 | M5 | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0104 | M5 | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 AR230289000 | M5 | 1.7 – 2.7 | 13.1 | 13.5 | 6.4 | 9.5 | ||
| C200 0306 | M5 | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0206 | M5 | 2.1 – 3.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0106 | M5 | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0312 | M6 | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0112 | M6 | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0114 | M6 | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0212 | M6 | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0214 | M6 | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0314 | M6 | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0215 | M6 | 2.1 – 3.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0116 | M6 | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0118 | M6 | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0324 | M8 | 0.7 – 1.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0326 | M8 | 1.8 – 2.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0328 | M10 | 0.7 – 1.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0330 | M10 | 1.8 – 2.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0320 | 1/4UNC | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0220 | 1/4UNC | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0120 | 1/4UNC | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0322 | 1/4UNC | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0222 | 1/4UNC | 2.1 – 3.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0122 | 1/4UNC | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0336 | 3/8UNC | 0.7 – 1.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0338 | 3/8UNC | 1.8 – 2.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0332 | 5/16UNC | 0.7 – 1.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0334 | 5/16UNC | 1.8 – 2.6 | 19.0 | 17.0 | 7.1 | 12.8 | 3.2 | 3 |
| C200 0316 | 0BA | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0216 | 0BA | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0318 | 0BA | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0218 | 0BA | 2.1 – 3.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0308 | 2BA | 0.7 – 1.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0108 | 2BA | 0.7 – 2.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0208 | 2BA | 0.7 – 2.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
| C200 0310 | 2BA | 1.8 – 2.6 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 3 |
| C200 0110 | 2BA | 2.2 – 3.1 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 1 |
| C200 0210 | 2BA | 2.1 – 3.0 | 14.0 | 14.0 | 5.8 | 9.5 | 0.8 | 2 |
